Eaton Fuller 18-Speed Transmission for Sale | RTLO-18918 / RTLO-22918 Roadranger | Class 8 Heavy-Duty Manual

Discover the Power of Eaton Fuller RT-Series 18-Speed Manual Transmissions

The Eaton 18-speed transmission is the most respected manual transmission in heavy-duty Class 8 trucking, where flexibility and endurance are critical characteristics. It has many gears, allowing the driver to easily move from low-speed launch torque on steep grades and heavy loads to smooth overdrive cruising at highway speeds. This Eaton 18-speed Transmission for Sale at our store is a manual transmission that requires skilled clutch and shifter coordination, demanding driver expertise but delivering exceptional control over power delivery and durability. This makes the Eaton 18-speed the most preferred transmission for owner-operators and fleet managers who prioritize reliability, longevity, and the maximum mechanical efficiency of a direct manual driveline.

Why Choose an Eaton 18-Speed Transmission?

• Wide Range of Gear Ratios: From the deep-reduction low range (1st gear 14.66:1) for heavy starts on steep grades to the overdrive ratios (9th gear 3.42:1) for fuel-efficient highway cruising. The 18-speed lets you keep the engine in its narrow peak-torque band regardless of load or grade.

• Splitter and Range Shifts: Enables precise gear selection with air-actuated splitter (low/high within each main gear) and range shifts (low range / high range), optimizing power delivery and engine efficiency.

• Manual Operation: Requires skilled clutch control for smooth gear transitions, enhancing driver control and adaptability in challenging conditions.

• Durability: Built to withstand heavy Class 8 loads (80,000+ lbs GCW) and demanding duty cycles, ensuring long-term reliability and reduced maintenance costs across high mileage.

• Enhanced Fuel Efficiency: Through versatile gear ratios and efficient direct mechanical power delivery, the transmission helps improve fuel economy by allowing the engine to operate at its most efficient RPM range across varying conditions.

Innovative and Patented Design

You might want this Eaton 18-speed transmission not just because you need one, but also because of the proven design elements that contribute to its performance and reliability:

• Precision Gear Design: State-of-the-art gear tooth configuration and material technology guarantee seamless engagement, longevity, and the ability to handle high-torque Class 8 diesel inputs.

• Splitter Mechanism: The patented Eaton splitter design splits each main gear into low and high, doubling the effective gear count and allowing precision RPM management across the operating range.

• Shift Quality and Control: Shift control technologies include synchronizer-free engagement (with the famous Eaton “double-clutching” or “float-shifting” technique), air-actuated splitter control on the shift knob, and air-actuated range selector. These reduce driver fatigue on long hauls.

• Efficiency Enhancements: Improved bearing arrangements, reduced internal friction, and twin-countershaft architecture distribute torque loading and improve overall mechanical efficiency.

• Durability Enhancements: Reinforced material in high-stress areas allows the unit to handle the heaviest loads in commercial trucking, including specialized heavy-haul applications.

Eaton 18-Speed Transmission Fits

Vehicles (Class 8 Tractors and Vocational Trucks):

• Freightliner: Cascadia, Coronado, Classic XL, Argosy (older)

• Kenworth: T680, T880, W990, W900 (older)

• Peterbilt: 579, 389, 567, 386 (older)

• Volvo: VNL series (long-haul), VNR (regional), VHD (vocational)

• Mack: Anthem, Pinnacle, Granite (vocational)

• International: LT Series, HX Series, ProStar (older)

• Western Star: 4900, 5700XE, 5700, 4700 (some applications)

Compatible Engines (Class 8 Diesel):

• Cummins: ISX15, X15, ISM, L9, M11 (older)

• Detroit Diesel: DD13, DD15, DD16, Series 60 (older)

• PACCAR: MX-13, MX-11

• Caterpillar: C15, C16 (older models, Cat exited on-highway in 2010)

• Volvo: D13, D16

• Mack: MP7, MP8, MP10

Quality Assurance

When you purchase a used Eaton 18-speed transmission from us, you can rest assured that you’re getting a quality product. Our process includes:

• Thorough inspection of all 18 forward gears and reverse

• Rigorous testing through both splitter and range positions

• Air system function verification

• External case visual inspection for cracks or weld repairs

Why Choose Our Used Eaton 18-Speed Transmissions?

• Thoroughly inspected with model designation confirmed (RTLO-18918 vs RTLO-22918)

• Competitive pricing vs Eaton dealer reman

• Expert technical support for installation questions

• Donor truck identification documented

FAQs
